Kinlock Falls

Kinlock Falls Model Home
4BR | 2BR | 2,280 sq ft
Model #327642B

The Ace 2.0 is a slightly larger version of the 1.0 model, with a similar floor plan. This home offers all the great features found in the original version, such as a spacious living area, bar top counter in the kitchen, LED lighting, Low E windows, “Lux Flor” linoleum flooring, 42” Oak Cabinet doors, Elongated commodes, a 50-gallon water heater and 29 Gauge Metal Roof.


Model
Features

  • 8’ FLAT CEILINGS RAFTERS 24” O.C. (ON CENTER)

    2’ X 4’ EXTERIOR WALLS 16” O.C.

    2’ X 4’ INTERIOR WALLS 24” O.C.

    2’ X 4’ MARRIAGE WALLS 16” O.C.

    R-11-11-21 : THERMAL ZONE II CONSTRUCTION

    MARRIAGE WALL GASKET SEAL (MULTI-SECTION ONLY)

    2’ X 6’ FLOOR JOISTS 12” O.C.

    FLOOR DECKING 5/8” OSB

    12” I-BEAM— ALL FRAMES WITH DETACHABLE HITCH

    DORMER(S) ON FRONT SIDE WITH STANDARD ROOF

  • ALL WOOD CABINET DOORS IN 3 COLORS

    “SOFT CLOSE” OVERHEAD DOORS AND DRAWERS

    DRAWER OVER DOOR CABINET DESIGN WITH LINED CABINETS

    CROWN MOLDING ON OVERHEAD CABINETRY

    CABINETS OVER WASHER/DRYER

    EXCLUSIVE “GLACIER” EDGE LAMINATE ROLLED-EDGE COUNTERTOPS WITH FORMED BACKSPLASH

  • BLACK WHIRLPOOL APPLIANCES STANDARD (STAINLESS OPTIONAL) WITH NATIONWIDE WARRANTY

    24 CUBIC FOOT SIDE-BY-SIDE REFRIGERATOR

    30” ELECTRIC RANGE (COIL EYE)

    DISHWASHER (BLACK)

    BLACK EUROPEAN RANGE HOOD

  • 29 GAUGE POWER RIB “COOL CHEMISTRY” COIL COATED METAL ROOFING WITH “TECH SHIELD” OSB ROOF DECKING

     PREMIUM GAUGE VINYL SIDING INSTALLED ON “TALLWALL” OSB SHEATHING WITH MOISTURE BARRIER (HOUSE WRAP) UNDER VINYL SIDING

    JAMES HARDIE FASCIA BOARD (2 COLORS)

    RESIDENTIAL RAISED PANEL SHUTTERS ON FRONT DOOR SIDE

    FULLY VENTED VINYL SOFFIT UNDER EAVES LOCATED IN A 8” OVERHANG

    VINYL THERMOPANE WINDOWS WITH LOW-E GLASS (NO GRIDS & TILT-SASH)

    38” X 82” 6-PANEL STEEL EXTERIOR DOOR WITH SUNBURST STYLE GLASS WITH FULL VIEW STORM DOOR ON FRONT (38” X 82”)

    COTTAGE REAR DOOR (OUT SWING) (36” X 80”)

  • ½” FINISHED SHEETROCK THROUGHOUT WITH LIGHT TEXTURE & SHERWIN WILLIAMS PAINT

    STOMP TEXTURED CEILINGS

    RESIDENTIAL SHELVING WITH ROD IN MBR CLOSET(S)

    WIRE SHELVING IN OFF BEDROOM CLOSETS

    3-1/4” CROWN MOLDING THROUGHOUT

    3” BASEBOARD THROUGHOUT

    3.5” INTERIOR DOOR & WINDOW TRIM (BLOCK STYLE)

    DOOR HANDLES, HARDWARE & LIGHTING PACKAGE (NICKEL)

    2-PANEL INTERIOR DOORS W/ NICKEL DOOR HANDLES

  • 200 AMP SERVICE

    TOTAL ELECTRIC APPLIANCES THROUGHOUT

    GFCI PROTECTED RECEPTACLES IN ALL BATHROOMS

    GFCI PROTECTED EXTERIOR RECEPTACLES

    VENTED FOR ELECTRIC DRYER

    4” LED RECESS CAN CEILING LIGHTING IN HOME (PER PRINT)

    SMOKE DETECTORS IN EACH BEDROOM & LIVING AREA (ALL SMOKE DETECTORS ARE INTERCONNECTED)

    EXHAUST FAN IN BATHS

    CEILING FAN IN THE LIVING ROOM

    LAVATORY LIGHTS OVER BATH LAVATORIES

    EXTERIOR LIGHT AT ENTRANCE DOORS

  • PEX FRESH WATER PLUMBING WITH PVC DRAIN LINES

    50-GALLON HIGH EFFICIENCY WATER HEATER WITH PRESSURE RELIEF VALVE WITH DUAL ELEMENTS

    METAL FAUCETS THROUGHOUT (CHROME)

    ELONGATED “WATER SAVER” PORCELAIN COMMODES

    ANTI-SCALD FAUCETS ON ALL TUBS & SHOWERS

    7” DEEP DOUBLE BOWL STAINLESS STEEL KITCHEN SINK WITH BLACK / STAINLESS INDUSTRIAL FAUCET

    1 PC. WHITE FIBERGLASS TUB/SHOWER COMBO IN OFF BATHS(42” X 60”)

    CERAMIC TILE SHOWER (ALL MULTI-SECTIONS)

    EXTERIOR FROST-PROOF FAUCET LOCATED (PER PRINT [1])

    OVAL WHITE CHINA LAVATORY

    SHUTOFF VALVES AT LAVATORY, SINKS, COMMODES, ICEMAKER, DISHWASHER & AT WATER INLET TO HOME Item description

  • “IN FLOOR” HEATING/COOLING SYSTEM INCLUDES ADJUSTABLE REGISTERS IN FLOOR (OPTIONAL UP-FLOW AIR AVAILABLE)

  • CONGOLEUM “LUXFLOR” (3 COLORS)

    17 OZ. CARPET INSTALLED OVER REBOND PAD WITH PERIMETER TACK STRIP (2 COLORS)
